AICTE MODROB – Rural
Sponsored
Artificial Intelligence (AI) and Internet of things (IoT) Skill Development and Research Lab
Configuration
|
Equipment |
Specifications |
|
NVIDIA® Tesla® V100 Tensor Core GPU Card |
32GB ECC Memory / 900 GB/s Memory Bandwidth/ 4096 Bit / 5120 Cuda Cores / 14 Tflops Single Precision floating point / 7 Tflops Double-Precision floating Point/ PCI Express 3.0
|
|
High End Workstation
|
INTEL XEON GOLD 6238 x 2. Intel C621 Chipset / 16 DIMMs – 12 Channel Maximum 2TB HDD RAM Support. 192 GB DDR-4 ECC RDIMM (32 GB x 6). 480 GB INTEL DATACENTER 4500 SERIES SSD. SATA 3.0, 6 GBPS / Enterprise Class. |
|
MATLAB |
Version R2020 |
|
Setup of IoT devices with Wireless Sensor Nodes |
Microcontroller and general purpose boards, LEDs, Boards, Sensors and wireless sensor nodes, Wi-Fi modules etc.
|
e-Yantra is a project sponsored by Ministry of Human Resource Development(MHRD) through the National Mission on Education through ICT(NMEICT)
Configuration
|
Sr. No. |
Equipments |
|
1 |
FireBird V 2560 |
|
2 |
Spark V Robo |
|
3 |
Fire Bird V P89V51RD2 adapter card |
|
4 |
Fire Bird V LPC2148 adapter card |
|
5 |
P89V51RD2 Development Board |
|
6 |
Raspberry-Pi 3 |
|
7 |
NRF24L01 |
|
8 |
Zigbee Modules 100m range |
|
9 |
Metal-gear Servo Motors |
|
10 |
Servo Motor Based Gripper kit for the Fire Bird V robot and Sharp GP2Y0A21YK0F infrared range sensor (10cm to 80cm) |
Digital Studio
(For e-Content Development)
Configuration
|
Sr. No. |
Item / Specifications |
Quantity |
Working Yes/No |
Photo |
|
1. |
Panasonic Smart TV panel (32 Inch LED) |
1 |
Yes |
|
|
2. |
Canon Professional 4K UHD camera (4K UHD, 20 x Optical Zoom, USB Power Supply) |
1 |
Yes |
|
|
3. |
OPS PC (Intel i5, 16 GB RAM, 256 SSD, Wi-Fi Adapter) |
1 |
Yes |
|
|
4. |
Wacom Cintiq pen HD Display (Touch Module, Stylus, 1600 pressure level, 1920*1080 resolutions, 3in1 cable port) |
1 |
Yes |
|
|
5. |
Yamaha Audio Mixer |
1 |
Yes |
|
|
6. |
Fujitsu PC System
(Core i7 Processor, 256 GB SSD, 1TB HDD, 16 GB RAM, 19” Screen, 2GB GPU) |
1 |
Yes |
|
|
7. |
Ahuja Microphone |
1 |
Yes |
|
|
8. |
Softbox flash light portable umbrella set |
2 |
Yes |
|
Smart Classroom
Configuration
|
Sr. No. |
Item/Specifications |
Quantity |
Working Yes/No |
|
|||
|
1. |
View sonic Interactive Flat Panel (IFP-8650-5) |
1 |
Yes |
|
|||
|
2. |
View sonic Display Panel (IFP-CDE6520) |
3 |
Yes |
|
|||
|
3. |
OPS PC (Installed in Panel) |
2 |
Yes |
|
|||
|
4. |
Lumens AI Tracking Camera (VCTR40-1080P, 20X Optical Zoom, 3 track modes) |
1 |
Yes |
|
|||
|
5. |
Maxub Camera |
1 |
Yes |
|
|||
|
6. |
Yamaha Audio Mixer (6 channel mixing console, 2 Mic and 6 line input, XLR balanced output, 48V Phantom power) |
1 |
Yes |
|
|||
|
7. |
JBL Control Pro Speaker (200W Peak handling power) |
4 |
Yes |
|
|||
|
8. |
Bosch LBD Amplifiers (480W Peak power, multiple outputs, dual inputs) |
1 |
Yes |
||||
|
9. |
Milestone HDMI Extender |
1 |
Yes |
||||
|
10. |
Ahuja Microphone |
2 |
Yes |
High Configuration Machine
Configuration
|
|
|
Specifications |
|||||||
|
Brand |
Equipment |
Display |
Processer |
RAM |
RAM TYPE |
HDD |
SSD |
Graphics Card? |
|
|
Hp |
HP ProOne 400 G6 24 All-in-One PC |
24 IPS DISPLAY |
Intel(R) Core(TM) i5-10500 CPU @ 3.10GHz |
16 GB |
DDR4 |
1 TB |
-- |
-- |
|
|
Hp |
HP 202 G2 MT |
hp 18.5 LED Monitor |
Intel(R) Core(TM) i5-4570T CPU @ 2.90GHz |
8 GB |
DDR3 |
500 GB |
-- |
-- |
|
|
Hp |
HP 280 G1 MT |
hp 18.5 LED Monitor |
Intel(R) Core(TM) i3-4160 CPU @ 3.60GHz |
8 GB |
DDR3 |
1 TB |
-- |
-- |
|
|
Lenovo |
LENOVO 12B2A08SIH |
24 IPS DISPLAY |
12th Gen Intel(R) Core(TM) i7-1260P |
16 GB |
DDR4 |
-- |
1 TB-NVME |
-- |
|
|
Hp |
HP ProOne 440 G9 All-in-One |
24 IPS DISPLAY |
13th Gen Intel(R) Core(TM) i7-13700 |
16 GB |
DDR4 |
-- |
1 TB-NVME |
-- |
|
|
Hp |
hp200-G3-AIO |
21.5 FHD IPS Antiglare LED |
Intel(R) Core(TM) i5-8250U CPU @ 1.60GHz |
16 GB |
DDR4 |
1 TB |
-- |
-- |
|
|
Tyrone |
Camarero DS400TGV-48RT |
BENQ 27 HD LED Monitor |
Intel Xeon 6226R |
384 GB |
DDR4 |
24 TB |
3.8 TB |
32 GB |
|
